GOEBEL manufactures hopper cones that are second to none in strength and durability.
GOEBEL has 2 types of cones to choose from with every hopper bin – Regular Profile and Low Profile. Both hopper cone designs are manufactured using the stronger uni-cone design based on parallel sheets not pie shaped segments.
Regular Profile Hopper Cones
GOEBEL Regular profile cones cone with the following features:
- Clearance
- 9′ to 18′ cones come standard with 18″ clearance under slide gate.
- 21′ to 24′ cones come standard with 24″ clearance under slide gate.
- GOEBEL can custom design cones with any clearance.
- Slide Gates
- Lever style gate standard, can be upgraded to rack and pinion. Removable and can be mounted in 4 positions in quarter turn increments to make opening as convenient as possible. All slide gates come standard mounted on nylon rollers. No metal to metal contact to get stuck.
- Drip Collar
- Gate drip ring keeps moisture away from the gate to reduce spoilage.
- Manhole
- 22″ round manholes are standard on all GOEBEL hopper cones.
Low Profile Hopper Cones
GOEBEL Low Profile cones come with the following features:
- Height
- Reduces over all height of grain bin by 18″ to 24″.
- Auger Boot
- Built in auger boot eliminates need for auger hopper.
- Manhole
- 22″ round manholes are standard on all GOEBEL hopper cones.
The advantages of a low profile cones are,
- reduces the overall height of a grain bin by 17″
- no longer need to haul around an auger hopper
- no mess under your grain bin
Gallery
Prairie Steel is equipped with cranes on all of our delivery units to deliver right to your site and unload the cones and packages. There is no need to worry about damaging product when you are unloading it off the trailer or dragging cones off the deck.
Prairie Steel aeration systems come in 2 sizes for the 15 and 18 foot diameter cones. 18” diameter perforated pipe are the standard option for air. Aeration pipes can be upgraded to 24” to allow for more airflow into the bin. All sizes of perforated pipe come standard with 30 percent porosity to allow maximum airflow while eliminating grain from entering the holes in the pipe.
Prairie Steel has the largest skid available for the 2406- 10700 bushel bins to sit on gravel base. The 4 ring 4 x 4 skid. Prairie Steel uses a piece of I – beam to distribute the weight evenly over the 4 skids to eliminate deflection in the skid.
Prairie Steel manufactures the cross air system for the Goebel 21’ dia and the 24’ dia grain bins. The cross air system comes standard in 18” diameter and can be added in grain bins up to 6 tiers high.
